HOBBYWING Quicrun Combo 3250kv 3652SL G2 Motor & 10BL120 G2 ESC Sensorless - HW38030207

HOBBYWING Quicrun Combo 3250kv 3652SL G2 Motor & 10BL120 G2 ESC Sensorless  - HW38030207

Details on Hobbywing 10BL120 Sensorless Brushless ESC:

- Excellent waterproof (splashproof - NOT submersible) and dustproof performance makes this ESC suitable for use in bad weather and harsh environments.

- Smart freewheeling technology makes the esc more efficient when driving and lowers the operating temperature which improves the effiency and reliability of the esc.

- Built-in switch mode BEC, continuous current up to 5A, instant up to 10A, and support 6V/7.4V adjustable, means this esc is suitable for strong, high torque servos.

- Multiple protection functions including battery low voltage protection, esc overheat protection, throttle signal loss protection, current protection, capacitor overheat protection.

It has an independent programming port. When connecting the program card, it is not necessary to pull the throttle cable out of the receiver, which is more convenient to use.

Specs:

Cont. / Peak Current: 120A / 760A
Motor Type: Sensorless / Sensored Brushless Motor (only in sensorless node)
Applications: 1/10th Short course truck, Monster Truck
Motor Limit With 3S LiPo: KV < 4000 3660 size motor
Motor Limit With 4S LiPo: KV < 2600 4268 size motor
LiPo Cells: 2-4S LiPo
BEC Output: 6V / 7.4V adjustable, continous current 5A (Switch-mode)
Cooling Fan: Powered by built-in BEC
Size / Weight: 52.8(L) x 39.8(W) x 38.2(H)mm / 119g (Included wires & connectors)
Programming Port: Independent programming port

Warnings: Before using this product, read the instruction manual carefully. Ensure that the equipment is used appropriately to avoid damaging the ESC. The wrong usage will overheat and damage the electronics. It is important to ensure that all wires soldered are properly secured to avoid short circuits from happening. A good soldering station is recommended to do such a job to avoid overheating the circuit board as well as to ensure connections are properly soldered. Even though the product has relevant protective measures, always use it in a safe manner in accordance with the operating environment noted in the manual (e.g, voltage, current, temperature and etc). Always remember to disconnect the battery each time after using it. Failure to do so will cause the battery to be completely discharged, resulting in an unpredictable danger.

Details on Hobbywing 3250kv 3652SL Sensorless Brushless Motor:

- Explosive output power - 10% increase in maximum output power.

- Featuring excellent performance and 8% higher motor efficiency than other motors of the same specifications, the QUICRUN 3652 SL brushless G2 motor operates cooler under the same load than its competitors, making it an ideal choice for your next project.

- QUICRUN motors feature an explosion-proof rotor design with reinforced aluminum end plates. This advanced design improves balance and strength, as well as providing excellent protection for the internal components. Its high-strength tensile materials ensure reliable performance.

- This QUICRUN 3652 SL brushless G2 motor is a reliable choice crafted from high-hardness aluminum, a CNC end cover, and a 0.2mm ultra-thin low-loss silicon steel sheet. It is further enhanced with first-line brand high-precision and high-quality bearings and 200°C high-temperature-resistant enameled wire for strong performance and longevity.

- The QUICRUN brushless motor G2 features a modular detachable design for easy maintenance, allowing for thorough daily cleaning and repairs that extend the service life and optimize motor performance.

Specs:

KV: 3250KV
Lipo's: 2-3S
No-load Current (A): 4.0A
Diameter / Length: φ=36mm L=52mm
Shaft Diameter / Length: φ=3.175mm L=15mm
Bearing size (mm): Fr & Rr: D13xD5xT4
Pole: 4
Weight: 223g
Applications: 1/10 On-road, Buggy, MT/ SC Truck

Warnings: It is imperative to configure power components carefully and consult your vehicle manufacturer for advice; misassembly can lead to an overloaded motor and damage. Additionally, be sure to fasten wiring securely as shaking can bring about control problems. Additionally, never drive at maximum power without a pinion gear, as exceptionally high RPMs without any load can damage the motor. Furthermore, to prevent loss of magnetism, the motor casing should be kept below 100 degrees Celsius (212 degrees Fahrenheit).
