Traxxas X-Maxx 8S Manual 77086-4

Parts Listing

Chassis Exploded View

Front, Diff and Shocks Exploded View

Rear & Transmission Exploded View

Body Shell Exploded View

Modular Exploded View

Pinion & Spur Gear Chart

PLEASE NOTE: We have noticed some changes in X-Maxx since December 2021, Listed here:

OLDER TRUCKS STANDARD PARTS:

  • Front Steering Hub - #7737
  • Front Steer Hub Outer Bearing - #5106A
  • Front Steer Hub Inner Bearing - #5182A
  • Rear Drive Hub - #7752
  • Rear Drive Hub Outer Bearing - #5106A
  • Rear Drive Hub Inner Bearing - #5182A

NEWER TRUCKS NOW HAVE:

  • Front Steering Hub - #7737X
  • Front Steer Hub Outer Bearing - #5106A
  • Front Steer Hub Inner Bearing - #5196A
  • Rear Drive Hub - #7752X
  • Rear Drive Hub Outer Bearing - #5106A
  • Rear Drive Hub Inner Bearing - #5196A
